200w Handheld Jewelry Laser Welding Machine Water Cooling For Gold Silver Rings

Wuhan Linxuan Laser Co., Ltd
Contact Now

200w Handheld Jewelry Laser Welding Machine Water Cooling For Gold Silver Rings

Brand Name : LinxuanLaser

Model Number : LX-D6

Certification : CE FDA ISO

Place of Origin : Hubei, China (Mainland)

MOQ : 1

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 100units per month

Packaging Details : Standard exporting wooden package box

Laser Type : YAG

Use for : Welding,metal welding

Warranty : 2 Years

Laser power : 200w,400w

Laser wavelength : 1064nm Laser Welding Wire

Power supply : 220V /50HZ

Dimensions : 1100mm*650mm*1260mm

Application : Jewelry Welding Products

Contact Now

200w Hand-held Gold Silver Rings Jewelry Laser Welding Machine Water cooling

Description:

We are appreciated and known among our customers for manufacturing, supplying and trading the optimum quality of Automatic Laser Welding Machine. By using advanced machinery, our engineers make these machines in compliance with the industry set norms. Being a quality conscious name, we assure that the premium quality of the offered welding machines is never compromised.

Features

Optimum Performance

Low Maintenance

Sturdy Construction

Application Industrial

Jewelry laser welding machine widely used in aviation, aerospace, sports goods, jewel, golf head, medical instrument, electronics, mechanical process, car industries. Suitable for gold, silver, copper, titanium, stainless steel and other metals' patch welding, spot welding, pocket repairing and jaw hand welding when mount parts.

200w Handheld Jewelry Laser Welding Machine Water Cooling For Gold Silver Rings

Specifications

Model LX-D6
Laser type YAG
Max. output power > 100W
Max. peak power 6KW
Pulse width 0.1~20ms
Laser welding focus length 110~130mm
Laser welding frequency 0~20Hz(0 is single spot welding)
Laser welding depth 0.01~3mm
Cooling water temperature ≤40℃
Cooling water flow 10L/min
Spot size adjustable range 0.3 ~ 2 mm
Power consumption 4KW
Power supply 220V±5%/50Hz
Dimensions(LxWxH) 1000*490*1220mm
